Fabricated from 3/16" Steel Plate, insulated with 4 inches of 2300 degree Ceramic Fiber Insulation on the walls of the heater enclosure. Insulation is attached with stainless steel stud welded pins and reinforced with stainless steel wire cloth covering the ceramic fiber.
All burner zone piping is welded. Forged steel threaded pipe fittings are only used outside of the direct heat zone. Mixing chambers are stainless steel rather than carbon steel for extended life and reduced maintenance. Burner is supplemented with an LPG Vapor Generator to ensure positive vapor pressure to the burner in cold weather operation. Capable of developing more than 8,000,000 BTU per coil, or over 32,000,000 BTU in multi-pass combinations.
Coil Piping Systems are fabricated from SA-106 Gr. B Seamless Steel Pipe in SCH 40 or SCH 80, per customer requirements. All weld fittings are SA 234 WPB Seamless Forged Steel and welded with 70,000 PSI tensile strength filler welding material. All pipe and fittings used in each coil are supplied with Material Test Reports. Each coil is hydro-tested to 800 PSI for SCH 40 Pipe and 1600 PSI for SCH 80 Pipe.
Julbert has a long track record of manufacturing oil field skids of the highest quality and durability. Through our proven, flexible manufacturing approach, we’re equipped and ready to provide your custom manufactured oil field skids.
Julbert can handle structural, process piping configuration changes and repairs, per customer requirements or concept designs.
Julbert Inc. is equipped with a steel fabrication facility servicing a wide range of customers and industries throughout the United States.
